• Hot water safety lock
  • No spill sealed system
  • #304 stainless cold reservoir
  • #304 stainless hot tank
  • #304 stainless waterways
  • Leak prevention
  • One piece blow molded polyethylene cabinet
  • Free standing internal structure
  • Carry handle


A robust bottle water dispenser with a classic design. The Aspen is the perfect water cooler for home and office delivery. Featuring Stainless tanks and a one-piece blow molded cabinet. The Aspen is built to perform and is backed by our company known for innovation, quality and support.


Power rating Single phase
100-115VAC 60Hz
220-240VAC 50Hz
Standard current HOT & COLD: 4.5-5.1A
Cold 85W
Hot 400W
Cold Compressor Single phase motor
Refrigerant R134a
Temp range 5-10°C (41-50°F)
Capacity 3.47L(0.9 gal)
Hot Heater Band heater
Temp range 74-92°C (165.2-197.6°F)
Temp control 82-89°C (179.6-192.2°F)
Capacity (External Heater) 1.47L (0.3 gal)
Noise (sound power level) 44dB(A)
Refrigerant charge 34g (1.2 oz)
Product weight HOT & COLD: 12kg(26.5 Ib) COOK & COLD: 11.5kg (25.4 Ib)
Product boxed weight HOT & COLD: 13kg (28.6 Ib) COOK & COLD: 12.5kg (27.6 Ib)
Product dimensions 320(W) X320(D) X980(H)mm
12.6"(W) X 12.6"(D) X 38.6"(H)
Product boxed dimensions 330(W) X 340(D) X 1000(H)mm
12.9"(W) X 13.3 "(D) X 39.4"(H)
Loading quantity 20' Container: 238Units
40' Container: 504Units
IEC protection class Class 1
Certifications C-CSA-US, EPA


Specifications Data

  • 110V Aspen Bottled Water Dispenser (Hot & Cold)           → Download
  • 220V Aspen Bottled Water Dispenser (Hot & Cold)          → Download
  • 220V Aspen Bottled Water Dispenser (Cook & Cold)           → Download


  • High-Resolution photos                                                   →   Download
